Audiolab 7000A Integrated Amplifier (Silver)

Audiolab 7000A is a 2 x 70W into 8 Class AB integrated amplifier accomodating a huge selection of digital/analogue inputs. Featuring an in-built (MM) phono preamplifier, HDMI ARC, a full-colour LCD screen, dedicated headphone amp, Reference ESS Sabre DAC, and full MQA decoding, 7000A is the amp others are measured by.

Whatever the input source - analogue, digital, wireless or TV - the 7000A has been crafted to the same level of detail one has come to expect from audiolab, all with the latest tech to be fully equipped to cover many bases, yet it maintains a price point that keeps the Audiolab brand at the forefront of quality home audio. Dual analogue inputs cater for CD players and line-level sources, dual Coax and SPDIF inputs expand this for the digital sources while a Bluetooth aptX receiver serves up a solution for wireless audio playback and smart devices. Following the growing trend for direct living room integration of premium audio electronics and there for more in tune as the centrepiece of your home audio system, the 7000A takes connectivity to a new dimension with a built-in Audio Return Channel (ARC) connection for use with screens - thus bringing the audiolab dynamic to TV-app based music playback and home theatre. And let's not forget the direct-to-PC connection via USB.

Technical Specifications


Power Amplifier Section


• Rated Power Output: 2 x 70W (8), 2 x 110W (4) Class AB
• Frequency Response: 20Hz-20kHz (+/-0.3dB)
• Signal-to-Noise Ratio: 110dB (A-weighted)
• Total Harmonic Distortion: <0.003% (1kHz @40W / 8)


Preamplifier Section


• Gain: +6dB (line), +55dB (Phono MM)
• Input Sensitivity: 820mV (Line, Vol. = 0dB); 3.1mV (Phono MM Vol. = 0dB)
• Input Impedance: 10K (Line); 47K // 100pF (Phono MM)
• Frequency Response: 20Hz-20kHz (+/-0.1dB)
• Signal-to-Noise Ratio: >110dB (Line A-weighted), >76dB (Phono MM, A-weighted)
• Total Harmonic Distortion: <0.005% (1kHz @ 2V, Volume = 0dB)


Input/Output


• Analogue Inputs: 3 x Aux, 1 x Phono (MM), 1 x Power Amplifier
• Digital Inputs: 2 x SPDIF (Coax), 2 x Optical, 1 x HDMI ARC, 1 x PC USB (USB B), 1 x Bluetooth (aptX/aptX LL)
• Audio Outputs: 1 x PRE Amplifier, 1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger


DAC


• D to A Converter: ES9038Q2M
• Total Harmonic Distortion (THD): <0.0005% (1kHz @ 0dBFS)
• Max. Sampling Frequency: Optical/Coax: 192kHz; PC USB: PCM 768kHz, DSD512


General


• Included Accessories: Remote Control
• Dimensions (H x W x D): 78 x 444 x 340mm
• Weight: 8.4kg
• Colour Choice: Black or Silver

photos and 3d renders are for illustrative purposes only. please see the specs sheet for the contents of this product.
